GSE DTH Drill Pipe Atlas Copco-Ingersoll Rand T4 IRT4

DTH drill pipes play a significant role in all DTH drilling, regardless of application, rock type, hole depth or drill rig. The key features of a high quality DTH tube are durability, accuracy and manageability.

Description

SINODRILLS GSE DTH Drill pipe Atlas Copco-Ingersoll Rand T4 IRT4

DTH drill rods transmit compressed air, so as to power the hammers to perform drilling work. Sinodrills DTH drill pipes are made of superior alloy and both thread ends are friction welded to the seamless steel pipe. The high pressure air is delivered to the DTH hammer by the DTH drill pipe, simultaneously, it transfers the rotation and press force to the DTH hammer.

Features

• Complete sizes for the option, suitable for different types of DTH drilling systems;

• The rods are made of cold-drawn steel with high manufacturing precision;

• Thread joint sturdily linked to the rod via friction welding;

• Nitriding process grants the thread joint good hardness, good wear quality and thus long lifespan.

Applications

Mining, quarrying, water well drilling, geothermal well drilling, foundation piling, etc.

Parameters

Diameter (A)	Wall (B)	Length (L)	Wrench Flat (E)	Recess Dia. (G)	Across Hex. (M)	Connection
mm	mm	mm	mm	mm	mm	Thread
102	8.38	6350	89	89	95	2 7/8” API REG
102	8.38	7620	89	89	95	2 7/8” API REG
114	8.56	6350	89	102	86	3 1/2” API REG
114	8.56	6350	89	102	86	2 7/8” API IF
114	8.56	7620	89	102	86	3 1/2” API REG
114	8.56	7620	89	102	86	2 7/8” API IF
114	12.70	7620	89	102	86	3 1/2” API REG
114	19.05	6350	89	102	86	3 1/2” API REG
114	19.05	7620	89	102	86	3 1/2” API REG
127	9.19	6350	89	102	89	3 1/2” API REG
127	9.19	7620	89	102	89	3 1/2” API REG
127	12.70	6350	89	102	89	3 1/2” API REG
127	19.05	7620	89	102	89	3 1/2” API REG
127	12.70	6350	89	102	89	3 1/2” API REG
127	12.70	7620	89	102	89	3 1/2” API REG
140	12.70	6350	89	127	86	3 1/2” Beco
140	12.70	7620	89	127	86	3 1/2” Beco
140	12.70	6350	89	127	86	4FH
140	12.70	7620	89	127	86	4FH
140	19.05	6350	89	127	86	3 1/2” Beco
140	19.05	7620	89	127	86	3 1/2” Beco
140	19.05	6350	89	127	86	4FH
140	19.05	7620	89	127	86	4FH
