DTH drill pipes play a significant role in all DTH drilling, regardless of application, rock type, hole depth or drill rig. The key features of a high quality DTH tube are durability, accuracy and manageability.
DTH drill rods transmit compressed air, so as to power the hammers to perform drilling works. Sinodrills DTH drill pipes are made of superior alloy and the both thread ends are friction welded to the seamless steel pipe.The high pressure air is delivered to DTH hammer by DTH drill pipe, simultaneously it transfers the rotation and press force to the DTH hammer.
• Complete sizes for the option, suitable for different types of DTH drilling systems;
• The rods are made of cold-drawn steel with high manufacturing precision;
• Thread joint sturdily linked to the rod via friction welding;
• Nitriding process grants the thread joint good hardness, good wear quality and thus long lifespan.
Mining, quarrying, water well drilling, geothermal well drilling, foundation piling, etc.
| OD (A) | Wall (B) | Lenght (L) | Across Flat (C) | Flat Length (E) | Recess Dia. (G) | Connection |
| mm | mm | mm | mm | mm | mm | Thread |
| 89 | 9.35 | 6096 | 82 | 70 | 70 | 2 3/8” API IF |
| 89 | 8.56 | 6096 | 98 | 57 | 89 | 3 1/2” API REG |
| 89 | 8.56 | 7620 | 98 | 57 | 89 | 2 2/8” API IF |
| 89 | 8.56 | 7620 | 98 | 57 | 89 | 3 1/2” API REG |
| 89 | 8.56 | 7620 | 98 | 57 | 89 | 2 7/8” API IF |
| OD (A) | Wall (B) | Length (L) | Across Flat (C) | Flat Length (E) | Dist From Shoulder (G) | Connection |
| mm | mm | mm | mm | mm | mm | Thread |
| 114 | 8.5 | 6000 | 98 | 51 | 95 | 3 1/2” API REG |
| 114 | 8.5 | 6000 | 45 | 51 | 57 | 3 1/2” API REG |
